Product Details:
Place of Origin: CHINA
Brand Name: DONJOY
Certification: CE,3A,FDA
Model Number: CLX
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiation
Packaging Details: carton box
Payment Terms: T/T, LC, Credit Card
Contact Now
Detailed Product Description
Materials: Full Stainless Steel Type: CLX
Flow Rate: 5- 38T/H Inlet: 2" Thread / Clamp / Ferrule
Outlet: 1.5" Thread / Clamp / Ferrule Motor: 5.5KW / 4.0
Rotor: 5 - Leaves
High Light:

lobe rotary pump

,

high pressure pumps

KS-20-1, SS304 Stianless steel high purity beer pump for transfer fuilid control flow



Description

food Pump, Bear Pump, milk Pump

Options

1. Mechanical seal: SIC/SICE/EPDM, TC/TC,EPDM

2. Gasket: viton/NBR

3. Connection: Thread, Clamp, Flange(DIN,SMS,RJT,IDF)

4. Motor: 2900,1450,3600Min/1,50HZ,60HZ

5.Max Tempressure:130degree

6.Single Seal, Flush Seal.



Specification

Product Name:

CLX-20-1, SS304 Stianless steel high purity centrifulgl pump for transfer fuilid

Valve Body Material:

SS304/SS316L/1.4301/1.4404

Seal Material:

EPDM (Standard, FDA approval) FPM(Viton) and NBR

Max. Flow:

150 m3/h

Max. Speed:

3600 min-1

Max. Head:

70H(m)

Max. Working Pressure:

7 bar/99 PSI

Max. Working

Temperature:

130 °C

Mechanical seal:

SIC/SiC/EPDM(Standard), C/SIC, TC/TC

Sealing type:

Flushed double mechanical seal/single mechanical seal(standard)

Motor power:

5.5kw,7.5kw,15ke,18.5kw

Voltage:

110V, 220V, 380V,440V-460V

Motor:

ABB/domestic/SIEMENS

Structure Full stainless steel pump
Feature Anti - corrosion

Motor Frequency:

50HZ, 60HZ

Surface treatment:

Inner polished and Sandblast outside

Application structure:

KS/BS

Available connection:

Tri-Clamp, Thread, Flange

Available standard:

DIN, SMS, 3A, RJT, ISO/IDF

Low discharge option :

Low discharge/diaphragm valve/ball valve/butterfly valve

Packaging Details:

Plywood case or customerized. Or as per the request of customers.

Delivery details:

Usually within 20 days after receiving T/T down payment.



Applications

1. This pump is a whole including the motor and pump are made of stainless steel, not only high clean exterior and interior design, also online high-pressure water rinse. IP67 up to IP69 rating

2.This pump have a high discharge,low noise, igh flow, no dead-ends. high-performance and other technical characteristics. Mother and manufacture high purity materials. Compliance with ASME BPE and EHEDG high Standards. Certified 3A-02-10,CE-MD/06/42/EC.

3.In pieces the pump is very suitable for workplace clean workshop and high clean requirements, such as biological pharmacy, food and beverage, wine,fine chemical industry and other fields



Competitive Advantage
“DONJOY is the only company that pass nine series of products by American 3A certification organization in Asian sanitary pumps and valves field.”



CLX-20-1 high purity beer pumps,Food transfer pump, Water pump, Centrifugal Pumps 0



CLX-20-1 high purity beer pumps,Food transfer pump, Water pump, Centrifugal Pumps 1

Tag : Donjoy Centrifugal pump, Beer beverage pump,  Food grade pump
