FDA Stainless steel sanitary grade butterfly valves for fluid control

FDA Stainless steel sanitary grade butterfly valves for fluid control

    • FDA Stainless steel sanitary grade butterfly valves for fluid control
    • FDA Stainless steel sanitary grade butterfly valves for fluid control
    • FDA Stainless steel sanitary grade butterfly valves for fluid control
  • FDA Stainless steel sanitary grade butterfly valves for fluid control

    Product Details:

    Place of Origin: China
    Brand Name: DONJOY
    Certification: CE,3A,FDA
    Model Number: NO.

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Price: negotiation
    Packaging Details: carton box
    Payment Terms: T/T, LC, Credit Card
    Contact Now
    Detailed Product Description
    Product Name: Piston Sanitary Pneumatic Butterfly Valve With C-TOP Materials: 304 / 316L
    Size: DN10 - DN300, 1/2" - 12" Operation: Actuator
    Connection: Welding Seal Standard: 3A Certification
    Butterfly Disc: Forging

    FDA Stainless steel sanitary grade butterfly valves for fluid



    control








    Specifications







    Product Name:



    sanitary pneumatic butterfly valve



    Valve Body Material:



    SS304/316L



    Seal Material:



    EPDM (standard) FPM/SILICON/NBR, FDA177.2600



    Max Working Pressure:



    5Bar



    Max.Working Temperature:



    120 degree C



    Available  size:



    DN10-DN300, 1/2"-12"



    Available connection:



    Clamp / welding / thread / special connection



    Available standard:



    3A/DIN/SMS/RJT/ISO/IDF



    Operated:



    Manual,Pneumatic, Electric











    Handle application:



    Two-position handle, three-position handle, four-position



    pull handle, multi-position plastic handle and multi-position



    stainless steel handle



    Control:



    Smart valve positioner / C-TOP control / position sensor



    Certificate:



    3A/54-02 (1580), PED/97/23/EC, FDA.177.2600, ISO



    Application scope:



    Dairy,food, beverage, pharmacy, cosmetic, etc



    Feature of structure:



    Pneumatic 3pcs butterfly valve + sensor



    Option:



    With mini type C - TOP













    Classification



    Mixture proof butterfly valve;



    Double seat butterfly valve;



    Single seat butterfly valve;












    Material



    The material connected with others: AISI 316L / 1.4404



    The material in other part: AISI 304



    Seal ring: EPDM FDA 177.2600



    Inernal surface finish: Ra ≤ 0.8μm



    External surface finish: CNC fine machining












    Options



    Gasket: NBR / MVQ / FPM



    Pneumatic actuator of double acting



    Inductive position sensor



    C - TOP control head



    Position sensor












    Handle selection



    Two-position handle;



    three-position handle;



    four-position pull handle;



    multi-position plastic handle;



    multi-position stainless steel handle;












    Connection



    SMS, RJT, DIN, 3A, ISO, Clamped, welded and threaded etc.












    Packaging Details



    Bubble pack for each valve.



    Outside packing are carton or plywood cases.



    Or as per the request of customers.














    Delivery details



    Usually within 20 days after receiving T/T down payment.










    Drawing



    FDA Stainless steel sanitary grade butterfly valves for fluid control











    Performance of different sealing material

    FDA Stainless steel sanitary grade butterfly valves for fluid control
