SS316L Pneumatic Mixing Proof butterfly valve with Feedback F top ( Limit switch )

SS316L Pneumatic Mixing Proof butterfly valve with Feedback F top ( Limit switch )

    • SS316L Pneumatic Mixing Proof butterfly valve with Feedback F top ( Limit switch )
    • SS316L Pneumatic Mixing Proof butterfly valve with Feedback F top ( Limit switch )
  • SS316L Pneumatic Mixing Proof butterfly valve with Feedback F top ( Limit switch )

    Product Details:

    Place of Origin: China
    Brand Name: DONJOY
    Certification: CE,3A,FDA
    Model Number: NO.

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Price: negotiation
    Packaging Details: carton box
    Payment Terms: T/T, LC, Credit Card
    Contact Now
    Detailed Product Description
    Product Name: SS316L Pneumatic Mixing Proof Butterfly Valve With F Top ( Limit Switch ) Materials: 316L
    Size: DN50-DN100 Operation: Actuator/F Top
    Connection: Welding Seal: EPDM, FPM, SILICONE, NBR
    High Light:

    stainless butterfly valves

    ,

    pneumatic butterfly valve

    SS316L Pneumatic Mixing Proof butterfly valve with feedback unit F top ( Limit switch )

    Specification

    Product Name:

    SS316L Pneumatic Mixing Proof butterfly valve with F top( Limit switch )

    Valve Body Material:

    316L

     Seal Material:

     EPDM (standard) FPM/SILICON/NBR, FDA177.2600

    MaxWorking Pressure:

    10Bar

    Max.Working Temperature:

    120 degree C

    Available  size:

    2"-4"

    Available connection:

    Clamp/welding/thread/special connection

    Available standard:

    3A/DIN/SMS/RJT/ISO/IDF

    Operated:

    Manual,Pneumatic, Electric

    Handle application:

    Two-position handle, three-position handle, four-position
    pull handle, multi-position plastic handle and multi-position stainless steel handle

    Control:

    Smart valve positioner / C-TOP control / position sensor

    Certificate:

    3A/54-02 (1580), PED/97/23/EC, FDA.177.2600, ISO

    Application scope:

    Dairy,food, beverage, pharmacy, cosmetic, etc

    Surface finishing:

    Ra≤0.8μm

    Artwork:

    Forging


    Application :
    The mixproof butterfly valve as a process element for the separation of media is suitable for a variety of applications:
    1. In CIP systems, for separating CIP media
    2. In flush-out processes
    3.In water management
    4. As pipe section shut-off valve for separating media
    5. In CIP/Gas management (breweries)
    6. At storage tanks for separating products(CIP)
    7.As CIP return valve in a valve matrix
    8. Preferably suitable for liquid and gaseous media without suspended matters/particles


    Operating Principle
    1.Double seat mixproof butterfly valve (Type A) Valve closed Position When the valve is in the non-actuated position(off position), medium A and medium B are reliably separated. The leakage cavity open towards the atmosphere in this case. After switching, the medium in the valve disk leakage areas can drain by gravity(1), The connection is also served as a leakage indicator.


    Valve open Position
    When the valve open, the leakage paths towards the atmosphere are closed. Cleaning of the leakage cavity The leakage paths can be cleaned/flushed if necessary. For this purpose, the two cleaning
    connections can be integrated in to the CIP circuit. It can be flushed when the valve is closed. The cleaning pressure in the supply line should be slightly lower than the inside process pressure( hygienic aspects)
