Stainless steel Elbow Fittings, SS316L 90 Degree Long radius Bend,Sanitary welding fitting

Stainless steel Elbow Fittings, SS316L 90 Degree Long radius Bend,Sanitary welding fitting

Heavy Duty Clamp

tri clover clamp

Place of Origin:

CHINA

Brand Name:

DONJOY

Certification:

CE/FDA/ISO/3A

Contact Us

Request A Quote
Product Details
Brand:
DONJOY
SIZE:
1/2"-10"
Polished:
Unpolished, Matt
Standard:
Sch10,Sch20,SCH40,SCH80,SCH5
Materials:
SS304/1.4301, SS316L/1.4404
Connection:
Welding
Payment & Shipping Terms
Minimum Order Quantity
30PCS
Packaging Details
Carton, Wooden Case
Delivery Time
10-30 working days
Payment Terms
T/T,L/C, Credit Card
Product Description

Stainless steel Elbow Fittings, SS316L 90 Degree Long radius Bend



Quick Detail

Fitting Elbow, Bend, Long radius fittings



Specification

Product Name:

Stainless steel Elbow Fittings, SS316L 90 Degree Long radius Bend

Material:

AISI304, AISI316L

Size:

1/2"-10"

Finish:

Sandblasting

Connection:

weld ends,socket Welding

Standard:

Sch10,Sch20,SCH40,SCH80,SCH5, JIS,DIN,INCH

Certificate:

ISO,3A,CE

Application scope:

Dairy, food, beer, beverage, pharmacy, cosmetic, Oil,Chemical

Packaging Details:

Shrink wrapped - carton - pallet . Or as per the request of customers



90 Degree Elbow

Donjoy 90 Degree Elbow and fittings compliant with USA 3-A sanitary standard, constructed from sanitary stainless steel 304 or 316L, provide solid, durability, problem-free for weld or assemble, available in ASME BPE, 3-A, DIN, SMS, ISO, I-line standard. 90 Degree Elbow and fittings widely used in food and beverage, brewing, pharmaceutical industries.

90 Degree Elbow Manufacturer

Donjoy Technology as 90 Degree Elbow Manufacturer in China, manufacture sanitary pipe fittings, sanitary valve, pump for more than 27 years. With USA 3-A, FDA, EU CE certification.

Stainless steel Elbow Fittings, SS316L 90 Degree Long radius Bend,Sanitary welding fitting 0

L2S 90 Degree Elbow Dimensions

Size (Tube OD) Dimensions
Outside Dimension Wall Thickness A B Radius
1/2″ 0.500″ 0.065″ 3.000″ 3.250″ 0.750″
3/4″ 0.750″ 0.065″ 3.000″ 3.375″ 1.125″
1 “ 1.000″ 0.065″ 2.063 2.563″ 1.500″
1-1/2″ 1.500″ 0.065″ 2.938″ 3.688″ 2.250″
2 “ 2.000″ 0.065″ 4.063″ 5.063″ 3.000″
2-1/2″ 2.500″ 0.065″ 5.188″ 6.438″ 3.750″
3 “ 3.000″ 0.065″ 6.313″ 7.813″ 4.500″
4 “ 4.000″ 0.083″ 8.313″ 10.313″ 6.000″
6 “ 6.000″ 0.109″ 11.000″ 14.000″ 9.000″

Tag : BPE ELBOW, Sanitary fitting elbow, Donjoy elbow
