DN65 Four Way SS316L Sanitary Sight Glass Zero Dead Angle

DN65 Four Way SS316L Sanitary Sight Glass Zero Dead Angle

DN65 Four Way SS316L Sanitary Sight Glass Zero Dead Angle

Product Details:

Place of Origin: CHINA
Brand Name: DONJOY
Certification: CE/FDA/ISO/3A
Model Number: NO.VSJ400N1

Payment & Shipping Terms:

Minimum Order Quantity: 1
Packaging Details: Carton, Wooden Case
Payment Terms: T/T,L/C, Credit Card
Contact Now
Detailed Product Description
Name: Four-way Sight Glass SIZE: DN40-DN100,1.5"-4"
Stanadard: DIN,3A,SMS,ISO Connection: Thread, Weld, Clamp, DIN, SMS, IDF
Polished: Mirror, Matt
High Light:

SS316L Sanitary Sight Glass

,

Four Way Sanitary Sight Glass

,

DN65 Sanitary Sight Glass

Four way sight glass, Zero Dead angle sight glass



Quick Detail

Four-way Sight Glass

Size:DN40-DN100,1.5"-4"

Gasket: EPDM,PTFE

Working temperature(basic):-10 to 150 degree

Working temperature(basic with lamp):-10 to 80 degree (depending on light heat resistance)



Specification

Product Name:

Four way sight glass,Zero Dead Angle,Noretention sight glass,Rechargeable

Valve Body Material:

SS304/SS316L/1.4301/1.4404

Seal Material:

EPDM, NBR, FPM in accordance with FDA 177.2600

Sight glass:

tempered glass

Max.temperature:

 -10 to 150 degree

Battery:

use high light flashlight,rechargeable lithium battery(220V Battery for 18650); can use AC220V/110V power supply lighting.

Availably connection:

Clamp, Thread, weld, DIN, SMS, IDF

Availably standard:

DIN, SMS, 3A, ISO

Certificate:

3A/54-02 (1580), PED/97/23/EC, FDA.177.2600, ISO9001/2008

Application scope:

Dairy, food, beverage, pharmacy, cosmetic, etc

Packaging Details:

Plywood case or customerized. Or as per the request of customers

Delivery details:

10-20 days



Application
Four-way sight glass is comprised of stainless steel frame and tempered glass. Through it,operator can observe the flowing of liquid clearly and precisely in the fields of food, cosmestic,pharmaceutical and fine chemicals industires.


Technical Features:
No retention, zero dead angle, high lilght, white cold light source, waterproof, explosion-proof.Cable power supply supply AC 110V/220V, DC24V Wireless power supply, one charging can be used for 2-3 months(depending on the frequency of use)


Product drawing

DN65 Four Way SS316L Sanitary Sight Glass Zero Dead Angle 0

Product display

DN65 Four Way SS316L Sanitary Sight Glass Zero Dead Angle 1

Tag : 4 way sight glass, Sight glass with light.
