    Product Details:

    Place of Origin: CHINA
    Brand Name: DONJOY
    Certification: CE,3A,FDA
    Model Number: CLX

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Price: Negotiation
    Packaging Details: carton box
    Payment Terms: T/T, LC, Credit Card
    Contact Now
    Detailed Product Description
    Materials: Full Stainless Steel Type: CLX
    Flow Rate: 5- 38T/H Inlet: 2" Thread / Clamp / Ferrule
    Outlet: 1.5" Thread / Clamp / Ferrule Motor: 5.5KW / 4.0
    Rotor: 5 - Leaves
    High Light:

    lobe rotary pump

    ,

    high pressure pumps

    KS-20-1, SS304 Stianless steel high purity beer pump for transfer fuilid control flow



    Description

    food Pump, Bear Pump, milk Pump

    Options

    1. Mechanical seal: SIC/SICE/EPDM, TC/TC,EPDM

    2. Gasket: viton/NBR

    3. Connection: Thread, Clamp, Flange(DIN,SMS,RJT,IDF)

    4. Motor: 2900,1450,3600Min/1,50HZ,60HZ

    5.Max Tempressure:130degree

    6.Single Seal, Flush Seal.



    Specification

    Product Name:

    CLX-20-1, SS304 Stianless steel high purity centrifulgl pump for transfer fuilid

    Valve Body Material:

    SS304/SS316L/1.4301/1.4404

    Seal Material:

    EPDM (Standard, FDA approval) FPM(Viton) and NBR

    Max. Flow:

    150 m3/h

    Max. Speed:

    3600 min-1

    Max. Head:

    70H(m)

    Max. Working Pressure:

    7 bar/99 PSI

    Max. Working

    Temperature:

    130 °C

    Mechanical seal:

    SIC/SiC/EPDM(Standard), C/SIC, TC/TC

    Sealing type:

    Flushed double mechanical seal/single mechanical seal(standard)

    Motor power:

    5.5kw,7.5kw,15ke,18.5kw

    Voltage:

    110V, 220V, 380V,440V-460V

    Motor:

    ABB/domestic/SIEMENS

    Structure Full stainless steel pump
    Feature Anti - corrosion

    Motor Frequency:

    50HZ, 60HZ

    Surface treatment:

    Inner polished and Sandblast outside

    Application structure:

    KS/BS

    Available connection:

    Tri-Clamp, Thread, Flange

    Available standard:

    DIN, SMS, 3A, RJT, ISO/IDF

    Low discharge option :

    Low discharge/diaphragm valve/ball valve/butterfly valve

    Packaging Details:

    Plywood case or customerized. Or as per the request of customers.

    Delivery details:

    Usually within 20 days after receiving T/T down payment.



    Applications

    1. This pump is a whole including the motor and pump are made of stainless steel, not only high clean exterior and interior design, also online high-pressure water rinse. IP67 up to IP69 rating

    2.This pump have a high discharge,low noise, igh flow, no dead-ends. high-performance and other technical characteristics. Mother and manufacture high purity materials. Compliance with ASME BPE and EHEDG high Standards. Certified 3A-02-10,CE-MD/06/42/EC.

    3.In pieces the pump is very suitable for workplace clean workshop and high clean requirements, such as biological pharmacy, food and beverage, wine,fine chemical industry and other fields



    Competitive Advantage
    “DONJOY is the only company that pass nine series of products by American 3A certification organization in Asian sanitary pumps and valves field.”
