| Place of Origin: | CHINA |
| Brand Name: | DONJOY |
| Certification: | CE,3A,FDA |
| Model Number: | NO.VZB40 |
| Minimum Order Quantity: | 1 |
|---|---|
| Packaging Details: | carton box |
| Payment Terms: | T/T, LC, Credit Card |
| Product Name: | Ball Valve | Size Of Panel: | DN25-DN100 |
|---|---|---|---|
| Operation: | Pneumatic, Control Head,Manual | Temperature Of Media:: | 150 Degree |
| Connection: | Welded, Clamped, Thread, Flange | Body: | SS304/SS316L |
| High Light: | pneumatic ball valve,stainless steel ball valve |
||
1/2 inch Directly Non-retention full port ball valve with Clamped Connection
Specification
| Product Name: | 1/2 inch Directly Non-retention full port ball valve with Clamped Connection |
| Valve Body Material: | SS304 or SS316L |
| Seal Material: | PTFE |
| Max. Working Pressure: | 10Bar |
| Max. Working Temperature: | 150 degree C |
| Availably size: | DN25-DN100 or 1" - 4" |
| Availably connection: | Weld,Clamp,Thread, Flange |
| Availably standard: | DIN,SMS,3A |
| Ball Type: | Directly |
| Operated: | Manual,Pneumatic,Electric,control Head |
| Certificate: | FDA,CE,3A,ISO |
Applications:
The ball valve according to 3A and ASME BPE standard design, mainly used in pharmaceutical, food and beverage, wine, chemical and other industires
Torque Information
| SIZE | 1/2”-3/4” | DN25/1” | DN32/11/4” | DN40/1.5” | DN50/2” | DN65/2.5” | 3” | DN100/4” |
| Nm | 6 | 10 | 12 | 14 | 20 | 40 | 75 | 110 |
Technical Feature
All-inclusive tee design, no stranded high clean, meet the requirement of CIP and SIP sterilization and cleaning,and heat resistance of 180degree, the highest pressure 30Bar,automatic compensating sealing design, the advantages of samll torque, long service life,
FAQ
Q: Can I get some samples?
A:Yes Samples orders to come.
Q: What is our advantage?
A: We are factory ,so we have very competitive price.And we can response to your for your questions very quick.We have professiona QC team,so we can offer your high quality products and our qualtiy level is very stable.
Q: What is the delivery time?
A:A week for sample; 15-30days for mass production.
Q:What is the payment team?
A:L/C at sight ,T/T etc.
Q: Can I trust you
A: Absolute yes.We are Alibaba verified supplier.
Q: May I visit your factory?
A:Sure,welcome any time. We can also pick you up at airport and station.
If you need more information,Please do not hesitate to contact us.
