Whole stainless steel Rotary lobe pump /STUL-10 mini lobe pump

Large Image : Whole stainless steel Rotary lobe pump /STUL-10 mini lobe pump

Product Details:

Place of Origin:	Wenzhou, Zhejiang, China
Brand Name:	DONJOY
Certification:	CE,3A,FDA
Model Number:	STUR/STUL

Payment & Shipping Terms:

Minimum Order Quantity:	Negotiation
Price:	825.56USD/PCS
Packaging Details:	carton box
Delivery Time:	10-15 days
Payment Terms:	T/T, LC, Credit Card
Supply Ability:	1500pcs/month

Contact Now

Detailed Product Description

Material:	AISI 304/316L	Size:	STUL
Motor Power:	1.5kw-15kw	Connection:	Clamp(standard)
Max Temperature:	150 C/302 F	Gasket:	FPM(Viton), NBR, EPDM
Highlight:	lobe rotary pump , high pressure pumps

Whole stainless steel Lobe High Purity Pumps , Electric ABB Motor 2 leaves pump

Applications:
The pump is a positive displacement lobe rotor pump designed according to USA 3A standard.
The equipment is processed with USA 3A and very strict hygienic.
The pump is ideal for the transfer of viscous as well as low-viscous medium in the food-processing, cosmetics and pharmaceutical industries.

Specification

Material:	SS304/SS316L/1.4301/1.4404
Seal Material:	EPDM (Standard, FDA approval) FPM (option)
Max. Flow:	90m³/h / 395 GPM
Max.pressure:	12bar/ 174PSI
Max. working temperature:	150 ºC/ 302 ºF
Max. rev:	1450 rpm
Rotor Type:	2-leaves, 3-leaves, butterfly, signal butterfly
Mechanical seal:	SIC/SiC/EPDM(Standard)
Motor power:	1.5kw-15kw
Sealing option:	Sanitary single mechanical seal/Double mechanical seal with cooling system
Voltage:	110V, 220V, 380V
Surface treatment:	Inner polished and Sandblast outside
Availably connection:	Clamp, Thread Butt weld, Flange
Availably standard:	DIN, SMS, 3A, RJT, ISO/IDF
Operated:	Electric
Certificate:	3A/54-02 (1580), PED/97/23/EC, FDA.177.2600, ISO9001/2008
Application scope:	Dairy, food, beverage, pharmacy, cosmetic, etc
Packaging Details:	Plywood case or customerized. Or as per the request of customers
Delivery details:	Usually within 20 days after receiving T/T down paymenyt

Design and features:
Horizontal TUL
Vertical TUR
Bare-shaft construction
Butterfly rotor(standard)
Hygienic design of the attachment of the rotors
Sanitary mechanical seal, Easy cleaning and maintenance
Connections: Clamp(standard)
Applied to CIP cleaning and SIP sterilization

Options:
Mechanical seal: SIC/SIC/EPDM/TC/TC/EPDM
Flushed single or double mechanical seal
Gasket:FPM(Viton),NBR,EPDM
Relief valve at the front cover or external by-pass
Built-in safety valve
End-face heat jacket
Complete heat jacket
Vertical TUR series or Horizontal TUL series
Different drives and fixes:
1.Manual continuously variable transmission
2.Frequency converter adjust motor gear box
3.Fixed speed output transmission
Assembly on a stainless steel baseplate
Connection:Clamp(DIN32676, 3A, ISO), Thread(DIN, SMS, RJT, IDF), Butt weld, flange
Material certificates(3.1), roughness certificate
Motor tyoe B5. Motor frequency 50HZ,60HZ
Voltage(V) 220-240, 360-400, 420-460, 630-690
Whole stainless steel Rotary lobe pump /STUL-10 mini lobe pump 0
