Hygenic Inox Normal Close Pneumatic Clamp 316L Butterfly Valves

Hygenic Inox Normal Close Pneumatic Clamp 316L Butterfly Valves

    • Hygenic Inox Normal Close Pneumatic Clamp 316L Butterfly Valves
    • Hygenic Inox Normal Close Pneumatic Clamp 316L Butterfly Valves
  • Hygenic Inox Normal Close Pneumatic Clamp 316L Butterfly Valves

    Product Details:

    Place of Origin: China
    Brand Name: DONJOY
    Certification: CE,3A,FDA
    Model Number: NO.VDF100Q2

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Price: negotiation
    Packaging Details: carton box or wooden box
    Delivery Time: 10-30 working days
    Payment Terms: T/T, LC, Credit Card
    Supply Ability: 1000pcs per month
    Contact Now
    Detailed Product Description
    Product Name: Butterfly Valve Materials: 304 / 316L
    Size: DN10 - DN300, 1/2" - 12" Operation: Pneumatic Actuator
    Connection: Clamp,weld,thread,flange Feature: With Aluminum Actuator
    Structure: Butterfly
    High Light:

    316L Butterfly Valves

    ,

    Hygenic Inox Butterfly Valves

    ,

    316L pneumatic butterfly valve

    Hygenic inox normal close pneumatic clamp butterfly valve with intelligent horizontal positioner IL-TOP



    Specifications

    Product Name:

    Hygenic inox normal close pneumatic clamp butterfly valve with intelligent horizontal positioner IL-TOP

    Valve Body Material:

    SS304/316L

    Seal Material:

    EPDM (standard) FPM/SILICON/NBR, FDA177.2600

    Max Working Pressure:

    10Bar

    Max.Working Temperature:

    120 degree C

    Availably  size:

    DN10-DN300, 1/2"-12"

    Availably connection:

    Clamp/welding/thread/flange

    Availably standard:

    3A/DIN/SMS/RJT/ISO/IDF

    Operated:

    neumatic

    Control:

    Smart valve positioner / C-TOP control / position sensor

    Certificate:

    3A/54-02 (1580), PED/97/23/EC, FDA.177.2600, ISO

    Application scope:

    Dairy,food, beverage, pharmacy, cosmetic, etc

    Packaging Details:

    Bubble pack for each valve. Outside packing are carton or

    plywood cases. Or as per the request of customers.

    Delivery details:

    Usually within 20 days after receiving T/T down payment.



    Valve drawing

    Hygenic Inox Normal Close Pneumatic Clamp 316L Butterfly Valves 0

    Hygenic Inox Normal Close Pneumatic Clamp 316L Butterfly Valves 1

    Hygenic Inox Normal Close Pneumatic Clamp 316L Butterfly Valves 2



    Pneumatic actuator date

    Hygenic Inox Normal Close Pneumatic Clamp 316L Butterfly Valves 3

                           Double acting pneumatic actuator Torque Table
    Size Torque(N.M) Recommend valve size
    Butterfly valve Ball valve 3 way ball valve Industrial valve
    DJ052 21

    DN10-DN50,

    0.5"-2"

    DN10-DN32,

    0.5"-1.25"

    N/M N/M
    DJ063 37

    DN65-DN80,

    2.5"-3.5"

    DN40-DN50,

    1.5"-2"

    DN25-DN32,

    1"-1.25"

    DN25,1"
    DJ075 59 DN100,4" 2.5"

    DN40-DN50,

    1.5"-2"

    DN32-DN40,

    1.25"-1.5"

    DJ083 74

    DN125-DN150,

    5"-6"

    DN65,3" DN65,2.5" DN50,2"
    DJ092 114 DN200,8" DN80 3" DN65,2.5"
    DJ105 170

    DN250-DN300,

    10"-12"

    DN100,4" DN80 DN80,3"
    DJ125 292 N/M DN125,5" DN100,4" DN100,4"
    DJ140 439 N/M DN150,6" N/M DN150,6"
    DJ160 669 N/M DN200,8" N/M DN200,8"



                               Single acting pneumatic actuator Torque Table
    Size Torque(N.M) Recommend valve size
    Butterfly valve Ball valve 3 way ball valve Industrial valve
    DJ052-S 12.5-8.5

    DN10-DN32,

    0.5"-1.25"

    DN10-DN15,

    0.5"-0.75"

    N/M

    DN10-DN15,

    0.5"-0.75"

    DJ063-S 21.2-13.7

    DN40-DN50,

    1.5"-2"

    DN25,1"



    DN25,1" DN25,1"
    DJ075-S 292.2-21.2 DN65,2.5"-3" DN32,1.25"

    DN32,1.25"



    DN32-1.25"
    DJ083-S 46.5-31.6 DN80,3.5" DN401.5" DN40,1.5" DN40,1.5"
    DJ092-S 69.3-46.7 DN100,4" DN50,2" DN50,2" DN50,2"
    DJ105-S 99-63

    DN200-DN250



    DN65,2.5" N/M DN65,2.5"
    DJ125-S 159-105 N/M DN80,3" DN80,3" N/M
    DJ140-S 260-172 N/M DN100,4" DN100,4" DN80,3"
    DJ160-S 422-279 N/M N/M N/M DN100,4"





    Positioner IL-TOP

               Horizontal pneumatic positioner IL-TOP 1441 (Recommend version)
    Hygenic Inox Normal Close Pneumatic Clamp 316L Butterfly Valves 4                                 Description
    Analog signal input 4-20mA (Standard version)
    Analog signal input 4-20mA (standard version) +MODBUS RS485 bus control



                     Horizontal pneumatic positioner IL-TOP 1441 (Feedback version)
    Hygenic Inox Normal Close Pneumatic Clamp 316L Butterfly Valves 4                   Description
    Analog signal input /output 4-20mA 0-5/10V (Feedback version)
    Analog signal input /output 4-20mA 0-5/10V (Feedback version)+Process control version



    Horizontal pneumatic positioner IL-TOP 1441 -Separate type
    Hygenic Inox Normal Close Pneumatic Clamp 316L Butterfly Valves 6                   Separate positioner IL-TOP and control unit C-TOP





    Material
    The material connected with others: AISI 316L / 1.4404
    The material in other part: AISI 304
    Seal ring: EPDM FDA 177.2600
    Inernal surface finish: Ra ≤ 0.8μm
    External surface finish: CNC fine machining


    Options
    Gasket: NBR / MVQ / FPM
    Pneumatic actuator of double acting
    Inductive position sensor
    C - TOP control head
    Position sensor
    Connection type: SMS, RJT, DIN, 3A, ISO, Clamped, welded and threaded etc.
