| Place of Origin: | CHINA |
| Brand Name: | DONJOY |
| Certification: | CE,3A,FDA |
| Minimum Order Quantity: | 1 |
|---|---|
| Packaging Details: | carton box or wooden box |
| Delivery Time: | according to order |
| Payment Terms: | T/T, LC, Credit Card |
| Supply Ability: | 1000 Piece/Pieces per Month |
| Media: | Liquid | Operate Mode: | Pneumatic |
|---|---|---|---|
| Size: | DN25 - DN100 Or 1" - 4" | Max Pressure: | 10 Bar |
| Structure: | Single Seat Valve | Temperature: | -10℃ To 120℃ |
| Compressured Air: | 5-7bar | ||
| High Light: | Pneumatic Divert Reversing Seated Valves,Stainless Steel 316L Reversing Seated Valves,10bar Reversing Seated Valves |
||
304 316L Stainless Steel Single Seated Valves Pneumatic Divert Seat Valve
Specification
|
Product Name |
DONJOY stainless steel 304 316 hygienic sterilization configuration aseptic pneumatic divert seat valve |
|
Material of valve body |
SS304 / 316L |
|
Material of seal ring |
EPDM |
|
Max. working pressure |
10 bar |
|
Max. working temperature |
120°C |
|
Size |
DN25 - DN100 or 1" - 4" |
|
Connection |
Threaded, welded, clamped |
|
Standard |
DIN, SMS, RJT, 3A |
|
Operating mode |
Manual, Pneumatic, Positioner |
|
Certificate |
FDA, CE, ISO |
|
Double stop pneumatic actuator |
To adjust the regulator to slow the moving speed of actuator, anti - shocking and lengthen the lifetime |
|
Body seat |
double seats |
| Body type |
222type,221type,212type,211type,111type,121type,122type,112type |
| Feature | CIP/SIP cleaning |
|
Installation |
With double stop regulator |
Features
The material connected with others: AISI 316L / 1.4404
The material in other parts: AISI 304
Seal ring: EPDM FDA 177.2600
Internal surface finish: Ra ≤ 0.8μm
External surface finish: CNC fine machining
Options
Gasket: NBR / MVQ / FPM
The pneumatic actuator of double-acting
Inductive position sensor
C - TOP control head
Position sensor
Air consumption (L/One cycle)
| Size | Spring/iar | air/air |
| 85 | 0.12 | 0.24 |
| 113 | 0.21 | 0.42 |
| 132 | 0.45 | 0.9 |
| 180 | 1.00 | 2.00 |
Product drawings
Tag : Donjoy sanitary valves, Donjoy change over valve, Donjoy shut off valves
