Sanitary SS316l Self Priming Centrifugal Pumps For CIP Process

Sanitary SS316l Self Priming Centrifugal Pumps For CIP Process

SS316l Self Priming Centrifugal Pumps

Sanitary Self Priming Centrifugal Pumps

SS316l priming a centrifugal pump

Place of Origin:

CHINA

Brand Name:

DONJOY

Certification:

CE,3A,FDA

Model Number:

ZLX

Contact Us

Request A Quote
Product Details
Materials:
SS316L/SS304
Flow:
30T/24M,11KW
Mechanical:
Single Sealing Parts
Inlet:
3" Thread/Clamp/Ferrule
Outlet:
2.5" Thread/Clamp/Ferrule
Medium:
Flow Tranfering And Controlling
Payment & Shipping Terms
Minimum Order Quantity
1
Price
Negotiation
Packaging Details
carton box
Payment Terms
T/T, LC, Credit Card
Product Description

Stainless steel High Sanitary ZLX Self Priming Centrifugal Pumps for CIP process and Transfer



Tags : CIP Pump, Centrifugal pump, Circulation pump

Specifications

Product Name:

CIP self priming centrifugal pumps ZXL series for wine processing

Valve Body Material:

Stainless steel 304 / 316L

Seal Material:

EPDM (Standard, FDA approval) FPM(Viton) and NBR

Max. Flow:

50 m³/h

Max. Speed:

3600 min-1

Max. Head:

66H(m)

CIP selection:

As per real situation

Driving mode:

By impeller installed on the inlet.

Mechanical seal:

C/SIC/EPDM

Sealing type:

Flushed double mechanical seal/single mechanical seal (standard)

Motor:

ABB / domestic is optional

Motor Frequency:

50HZ, 60HZ

Surface treatment:

Inner polished and Sandblast outside

Application structure:

ZXL

Available connection:

Tri-Clamp, Thread, Flange

Available standard:

DIN, SMS, 3A, RJT, ISO/IDF

Operated:

Electic

Low discharge option:

Low discharge/diaphragm valve/ball valve/butterfly valve

Certificate:

3A/54-02 (1580), PED/97/23/EC, FDA.177.2600, ISO9001/2008

Application scope:

Dairy,food, beverage, pharmacy, cosmetic, etc

Packaging Details:

Plywood case or customerized. Or as per the request of customers.

Delivery details:

Usually within 20 days after receiving T/T down payment.


Applications


1. This pump is a sanitary lateral design self priming pump,it's suitable for food processing,
phamacy and chemical industry.
2. The pump is designed a side way pipe between inlet and outlet
3. It is specially designed for pumpling mterials containning air or gas, and it can also be used
for negative sution with prior priming as well as with filtration equipment
4. It can be sued for wine, oil,syrups, volatile products such as alcohol, acetone and other
solvents or with products at temperatures close to boiling point.However, the main use of this
pump is for cip recover.



ZLX SERIES VARIOUS APPLICATION

Brewery :  Beer, wort, Yeast, Water, CIP Solution

Dairy products : Milk, Cream, Yogurt, whey, saline, CIP Solution

Food: Deible Oil, Soup Sauce, Soup stock, Flvouring, Ice cream mixture

Other Application: Storage tank empty .



ZLX SERIES PUMP Inlet&outlet connection Standard

Connection: Thread, clamped, Flange, Aspetic Flange, KF etc

Standard: DIN, SMS,ISO, IDF, RJT, ASME BPE, 3A, I LINE



Suggestion of pump inlet/outlet connection distance



In order to ensure a certain self-priming capacity&stable operation  and  prolong the service lif of the self priming centrifugal pump, it is required to install strictly according to the inlet and outlet dimensions of the pump. It is strictly forbidden to use inlet pipeline smaller than the outlet size, otherwise it is easily cause pump shake, noise, NPSH increase, etc;the pump inlet connection needs to maintain a certian height,  it is recommeded that the straight pipe height be 15-25 times the diameter of inlet pipeline(As show in (D-03)

Sanitary SS316l Self Priming Centrifugal Pumps For CIP Process 0



Mechanical Design

Sanitary SS316l Self Priming Centrifugal Pumps For CIP Process 1

Donjoy DJ-ZLX Series self-priming centrifugal pump eachanical seal is researched and developed together with european swedish famous company. The mechanical seal is designed with pressure balance and super long working life. Can be disassembled and maintained easily without special tools. The sanitary purity is according to EU EHEDG, USA 3-A-02-11,FDA1772600 and so on . And has lots of configuaration.



Mechanical seal Materials option :



1. SIC/CEPDM, SIC/C/FKM, SIC/C/HNBR, SIC/SIC/EPDM, SIC/SIC/FKM, SIC/SIC/HNBR, TC/TCEPDM, TC/TC/FKM, TC/TC/HNBR.



ZLX Self Priming Centrifugal pump selection table :

Sanitary SS316l Self Priming Centrifugal Pumps For CIP Process 2

Drawing of the ZLX Pump



Sanitary SS316l Self Priming Centrifugal Pumps For CIP Process 3

Sanitary SS316l Self Priming Centrifugal Pumps For CIP Process 4

Flow rate and head
Sanitary SS316l Self Priming Centrifugal Pumps For CIP Process 5

Competitive Advantage
“DONJOY is the only company that pass nine series of products by American 3A certification
organization in Asian sanitary pumps and valves field.”
