Fruit Jam Transfer SS316L Sanitary Twin Screw Pump

Fruit Jam Transfer SS316L Sanitary Twin Screw Pump

Sanitary Twin Screw Pump

SS316L Twin Screw Pump

DIN Fruit Jam Transfer Pump

Place of Origin:

CHINA

Brand Name:

DONJOY

Certification:

CE/FDA/ISO/3A

Model Number:

LG/R

Contact Us

Request A Quote
Product Details
Brand:
DONJOY
Model:
LGR-20,LGR-30,LGR-70
Connection:
Welding, Weld, Clamp,Thread,
Materials:
SS316L
Standard:
3A,DIN,RJT
Driver:
Motor
Media:
High Viscosity/Low Viscosity, CIP
Payment & Shipping Terms
Minimum Order Quantity
1PCS
Packaging Details
Carton, Wooden Case
Payment Terms
T/T,L/C, Credit Card
Product Description

Flexible soluction Sanitary Stainless Steel Twin Screw Pump /Fruit Jam Transfer Pump



Flexible soluction for two - durection reversible, high pressure, high viscosity, Large particl, Pulse free, Liquid Delivery



Description
Double screw pump is used for complex working condition or material transportation and extraction with high-efficiency self-priming ability and transportable solid particles,gas-liquid mixture,high viscosity,low viscosity,etc


It is not only used for material extraction and transportation,also apply for CIP and SIP systems,can reduce pipeline,valve control and CIP exclusive pumps,which not only improve efficiency,but also save cost.


It has extra characteristics,but other volume pumps do not have, such as no pulse phenomenon, no particle damage, high pressure, speed range, larage flow range and so on.


Specifications


Product Name:

SS Twin Screw Pump Double screw pump for material transportation and extraction

Material:

100% stianless steel, products contact parts 316L

Seal Material:

SIC / SIC / EPDM (Standard, FDA approval)

Max. Flow:

110 m3/h

Max.pressure:

20 bar

Max. working temperature:

150 C

Max. rev:

3500 rmp

Max particles:

23mm

Motor power:

2.2kw, 3kw….22kw

Feature

Movable

Voltage:

110V, 220V, 380V,440v

Motor:

ABB,SEW, 50hz / 60hz

Surface treatment:

Ra≤0.6μm, EP=Ra0.4μm

Available connection:

Clamp, Thread Butt weld, Flange

Available standard:

DIN, SMS, 3A, RJT, ISO / IDF

Certification

3-A-02-11 NO.1759, FDA 177.2600 CE-MD/06-42 NO.705201402401-00

Application scope:

Dairy, food, beverage, pharmacy, cosmetic, etc

Delivery details:

Normally within 20 days after receiving T/T down payment.


Applications

Twin screw pump has strong self priming ablity, can transport solid particles, gas liquid mixture, high viscosity, low viscosity and other materials. The pump not only can extract and convey materials, but also apply for CIP and SIP systems, can reduce pipeline, valve and CIP exclusive pumps, which improve efficiency and save cost, It has extra characteristics, that other volume pump do not have, such as no pulse phenomenon, no particle damage, high pressure, wide speed range, large flow range and so on.
And used for complex working condition or material transportation and extraction with high-efficiency self-priming ability and transportable solid particles,gas-liquid mixture,high viscosity,low viscosity,etc.

Twin screw pump for CIP Cleaning and media delivery configuration
Fruit Jam Transfer SS316L Sanitary Twin Screw Pump 0
With its strong self priming capacity , the LG series screw pump have the alibity to deliver high viscosity and low viscosity medium, as well as cip liuqid extraction and cleaning functions. Choosing LG Serices screw pump will help you to reduce using cip dedicated pump and valve control system, it will save cost .




Design and features
1. material transportation and extraction
2. apply for CIP and SIP systems
3. no pulse phenomenon, no particle damage
4. high pressure, speed range, larage flow range and so on

Flexible soluction for two Direction reversible, High pressure, High Viscosity, Large Particle, Pulse free, Liquid Delivery.



Choose the right screw spacing for your process

Option 1: Large screw spacing, large flow rate, Can deliver larger particles, But the pressure will be lower compared with samll spacing screw

Option 2: Samll Screw spacing, lower flow rate but higher pressure, the particles that can be transported will also be smaller.

Fruit Jam Transfer SS316L Sanitary Twin Screw Pump 1
 Conbination of Twin screw PUMP

1 LG-R screw pump  (Inlet&outlet vertical with level)

2.LG-L Screw pump  (Inlet&outlet horizontal with level)

3.Screw pump + heating jacket

Fruit Jam Transfer SS316L Sanitary Twin Screw Pump 2

4. Variable frequency motor helical gear screw pump

5.Motor direct-connected screw pump

6.Screw pump with whole cover

7.Screw pump with whole cover

8.Screw pump with material mixing connector

Fruit Jam Transfer SS316L Sanitary Twin Screw Pump 3

9.Screw pump with external safety system

10.Screw pump with flanged hopper

11.Mechanical stepless speed regulating screw pump

12. Screw pump with trolley and console

Fruit Jam Transfer SS316L Sanitary Twin Screw Pump 4

13. servo motor speed reducing output screw pump


Selection table
Fruit Jam Transfer SS316L Sanitary Twin Screw Pump 5

Connection way
Fruit Jam Transfer SS316L Sanitary Twin Screw Pump 6

Transfer Direction ( Both direction)

Fruit Jam Transfer SS316L Sanitary Twin Screw Pump 7
